WL-PLX High Torque Planetary Gearbox
Unique multi-stage reduction ratio, precision, economical selectivity, precision and high efficiency output planetary gear type speed reducer, is the best combination of servo motor, stepper motor and other precision transmission mechanism.
High Torque Planetary Gearbox Manufacturers for Servo Motor
Our gearboxes come with a one-year warranty. Suitable for servo motor brands: Panasonic, Delta, Yaskawa, Shinjie, Huada, Fuji, Mitsubishi, Sanyo, Tamagawa, Siemens, Schneider, Omron, FANUC, TECO, Eston, Kobe, Kollmorgen, AMK, Parker, etc.
NSK & FAG bearings ensure long service time. Operate: Max input speed: 10000rpm (recommend 4500rpm). Lifetime Lubrication, 30000 hours service time. -25℃ to +90℃. Suitable for AC/DC servo motor, stepper motor, BLDC motor or anyother motor.
High torque servo planetary gearbox
plx high torque planetary gearbox
More data please check our PLX Catalog PDF:
WL-PLX Planetary Gearbox Catalogue Download
Advantages of woolars planetary gearbox manufacturer:
- Low backlash & accurate positioning, fully assist high precision servo motor.
- Long life and life time lubrication.
- Smallest in the same class, suitable even space is limited.
- Internal components are heat-treated high-strength alloy steel, good rigidity and large bearing capacity.
- Low loss gear design, transmission efficiency up to 97%.
- Easy to install.
1) Series introduce:
| WL-PLE series is round output flange. |
| WL-PLF series is square ouput flange. |
| WL-AL / WL-AF / WL-AH / WL-ZAL / WL-ZAF series are helical gearboxes, 0-3 arc/min (others are spur gearbox). |
| WL-ZPLE series is right angle & round output flange. |
| WL-ZPLF series is right angle & square output flange. |
| WL-PLS series is double shaft gearbox. |
| WL-PLH series is disc output type. |
| WL-PLX/ZPLX series is for 142mm 190mm and 242mm flange. |
| WL-VLF/WL-VLE series is for 78/90mm flange |
| WL-ZPT/WL-ZSPT series is for special use. |
2) Gearbox flange dimension:
40mm, 60, 64, 70, 75, 80, 90, 110, 115, 120, 140, 142, 155, 160,190, 242mm.
3) Ratio:
Stage 1: 3, 4, 5, 7, 10
Stage 2: 12, 16, 20, 25, 28, 35, 40, 50, 70
Stage 3: 64, 80, 100, 125, 140, 175, 200, 250, 350, 400, 500, 700, 1000
4) Backiash:
Stage 1: <12 arcmin (A series <3)
Stage 2: <15 arcmin (A series <6)
Stage 3: <18 arcmin (A series <8)
Factory and Workshop:
Planetary gear reducer factory
Testing-Packaging-Warehouse：
3 tests before leave factory, shipping by air within 3-5 days to customer hand (also support sea shipping). Wooden or carton package according to weight.
Testing-Packaging-Warehouse
WOOLARS planetary gearbox manufacturer application range:
Aerospace, CNC machine tools, cutting and welding equipment, textile printing and dyeing machinery, packaging machinery, food machinery, ships, communications, plastic machinery, electronic equipment, engineering machinery, metallurgical machinery, petroleum machinery, marine machinery, construction machinery, glass machinery, Robotic arm, robot, medical equipment and other applications.
More gearbox please check: Link
You can also subscribe us on: Facebook
Note: We are source factory provide a one-year warranty. OEM/ODM is available, above are only typical models. More information or customized reducer gearbox, please contact us.
